Glass fiber resilient blanket

Quick Details:

Package: Plastic packing
Density: 16kg/m3
Thickness: 75、85、100、150mm
Mean tensile strength: ≥18kpa
Delivery time: 7-10 days
Payment terms: TT, LC

Introduction

Glass Fiber Resilient Blanket for LNG Storage Tank Cryogenic Insulation

EcoIn’s glass fiber resilient blanket is an essential structural component of cryothermal insulation systems for LNG storage tanks. This glass fiber resilient blanket is positioned between the inner tank wall panel and expanded perlite, absorbing side pressure under various operating conditions: pre-cooling contraction of the inner tank, hydraulic expansion during LNG operation, and expansion during empty-maintenance cycles. According to Wikipedia, glass fibers are prized in demanding insulation applications for their excellent thermal stability, flexibility, and mechanical resilience at cryogenic temperatures. EcoIn’s glass fiber resilient blanket maintains LNG storage system integrity and prevents damage to inner tank siding throughout service life.

Technical Parameters

Propertities	Unit	Specification
Density Tolerence	kg/m3	16±10%
Fiber Diameter	μm	6.8
Coefficient of resilience	/	>0.44
Conductivity	W/(m·k)	≤0.04 (0℃) ≤0.032(-10℃)
Mean tensile strength	kPa	≥18
Combustion property	/	Class A1
Water content	%	≤0.4
Adhesion content	%	20±5(weight)
Width	mm	1200
Normal thickness	mm	75、85、100、150
Length	m	According to user demand
Size tolerance	/	width:+7mm,-0mm length:+2%，-0% Thickness after development :+15mm，-0mm

Features

EcoIn Glass wool blanket has below features:

1. Excellent Resilience:

The coefficient of resilience>0.44 has excellent resilience. In addition to absorbing the lateral pressure of the tank’s expanding perlite under various conditions,the elastic felt itself maintains its integrity.

2.Excellent fire resistance:

A1 grade non-combustible fireproof material, greatly improve the safety performance.

3.Excellent drying effect:

For example,when the moisture content of the material in the low temperature storage tank is too high,the replacement gas can not dry the insulation material in time, resulting in the tank body frost resulting in safety risks. The moisture content of glass fiber resilient blanket is as low as 0.4%,which has a very excellent drying effect to ensure the timely drying of the cryogenic insulation system of the LNG tank and ensure the stable operation of the system.

4.Excellent thermal insulation performance:

The thermal conductivity of glass fiber resilient blanket is as low as 0.040 W/m.k,with good thermal insulation effect, energy saving and environmental protection.

5.High tensile strength:

The fibers of resilient blanket are tightly bonded with each other, with strong gripping strength between fibers and tensile strength of no less than 18 KPa, so that the product has stronger tensile performance, and ensures the uniform distribution of fibers after installation and use of the product, without local thickness and insufficient strength.

Application

Glass fiber resilient blanket: EcoIn manufactures this cryogenic glass fiber resilient blanket for LNG storage tank insulation systems, supplying customers in the LNG, petrochemical, and offshore industries worldwide.

Frequently Asked Questions – Glass Fiber Resilient Blanket

What is a glass fiber resilient blanket used for?

A glass fiber resilient blanket is used as the cryogenic insulation layer inside LNG storage tanks. Positioned between the inner tank wall panel and expanded perlite, this glass fiber resilient blanket absorbs side pressure variations from pre-cooling contraction, LNG hydraulic expansion, and empty-maintenance cycles — maintaining tank structural integrity and preventing damage to inner tank siding.

What specifications does EcoIn's glass fiber resilient blanket offer?

EcoIn’s glass fiber resilient blanket is available in density 16 kg/m³, thickness 75 mm, 85 mm, 100 mm, and 150 mm, with mean tensile strength ≥18 kPa. Standard delivery is 7–10 business days. Payment terms: TT and LC.

Is the glass fiber resilient blanket suitable for cryogenic temperatures?

Yes. EcoIn’s glass fiber resilient blanket is specifically engineered for cryogenic service at temperatures as low as -162°C in LNG storage tank applications. Glass fibers maintain excellent flexibility and mechanical properties under extreme cold, making this glass fiber resilient blanket ideal for LNG cryothermal insulation systems.

What is the lead time for glass fiber resilient blanket orders?

Standard lead time for EcoIn’s glass fiber resilient blanket is 7–10 business days. Custom thickness or density may require additional time. Inquiries are replied within 24 hours — contact EcoIn for a prompt quotation.
