Aluminum coil with polysurlyn is a factory-laminated protective jacketing used on pipe and equipment insulation in refineries, petrochemical plants, and HVAC systems. EcoIn supplies aluminum coil with polysurlyn in alloy 1060, 3003, and 3105, with a heat-bonded 3-mil polysurlyn moisture barrier, in 0.4–1.2 mm thickness, in smooth, stucco embossed, or corrugated finishes.
EcoIn Aluminum Jacketing has a bare outer surface and comes standard with a 3-mil thick polysurlyn moisture barrier heat-laminated to the interior surface to help prevent galvanic corrosion by contact of dissimilar metals in the presence of moisture.
Standard Sizes
| Thickness(inch) | Thickness(mm) | Width(mm) | Length(m) | Suggested Application |
|---|---|---|---|---|
| 0.016 | 0.4 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD below 36”(914mm) insulated lines |
| 0.020 | 0.5 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD below 36”(914mm) insulated lines |
| 0.024 | 0.6 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | OD 36”-8′ (914mm-2.19m) insulated lines&equipment |
| 0.032 | 0.8 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | special applications where extra thickness and protection is required, such as fabricated tank head covers and other special fabrications |
| 0.040 | 1 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | special applications where heavy mechanical is required |
| 0.050 | 1.2 | 914, 1000, 1219 | 30, 60, 90, coil or sheet | flat ducts or precipitators. Also recommended for areas subject to high wind conditions |
Remarks: Other sizes available upon request.
Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Zn | Mg | Ti | Cr | Other Elements | AL | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Each | Total | ||||||||||
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.05 | 0.03 | 0.03 | – | 0.03 | 99.6min | |
| 1100 | Si+Fe=0.95 | 0.05-0.20 | 0.05 | 0.10 | – | – | – | 0.05 | 0.15 | 99.0min | |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.50 | 0.10 | – | – | – | 0.05 | 0.15 | reminder |
| 3105 | 0.6 | 0.7 | 0.30 | 0.30-0.80 | 0.40 | 0.20-0.80 | 0.10 | 0.20 | 0.05 | 0.15 | reminder |
| 5005 | 0.3 | 0.7 | 0.20 | 0.20 | 0.25 | 0.50-1.10 | – | – | 0.05 | 0.15 | reminder |
EcoIn aluminum sheet has below features:
Ecoin aluminum sheet can be used as:
Click below to see Typical Project
Your Content Goes Here
Related Products
Aluminum Coil with Polysurlyn – FAQ
Aluminum coil with polysurlyn is protective metal jacketing with a factory-laminated polysurlyn moisture barrier, used to weatherproof pipe and equipment insulation. EcoIn aluminum coil with polysurlyn is available in alloy 1060, 3003, and 3105 per ASTM B209 and ASTM C1729. According to Wikipedia on aluminium cladding, polysurlyn-laminated aluminum jacketing is the industry standard for galvanic corrosion prevention.
