Quiet Guard Stone Wool Insulation Batt

Stone Wool batts safe n sound comfort batt18

Quick Details:

Material: Stone Wool (Mineral Wool)
Nominal Density: 2.5 lb/ft³
Width: 15.25″ for 16″ O.C. | 23″ for 24″ O.C.
Length: 47″ (wood stud) / 48″ (steel stud)
Thickness: 3″ / 3.5″ / 5.5″ / 6″ / 7.25″ / 8″
Fire Performance: Non-Combustibility — Class A1 | Flame Spread Index 0
Thermal Conductivity: 0.034–0.043 W/(m·K) @ 25℃
Packing: Heat-shrink film, palletized for container shipping
Delivery time: 20–30 days (FOB)
Payment terms: TT, LC

Introduction

Quiet Guard Stone Wool Insulation Batts are premium-grade mineral wool products engineered for the North American residential and light commercial market. Made from natural volcanic rock (basalt) and recycled slag, Quiet Guard batts deliver outstanding thermal resistance, acoustic attenuation, and Class A1 non-combustible fire performance — all in a friction-fit batt that installs without mechanical fasteners.

Quiet Guard AcousBatt™ — Interior Acoustic & Fire Series

Engineered for interior partition walls, floors, and ceilings where noise control is the primary goal. At 3″ or 6″ thick, the high-density stone wool fiber structure absorbs airborne sound and reduces impact noise transfer while providing a non-combustible thermal break.

Quiet Guard ThermaBatt™ — Exterior Thermal & Acoustic Series

Engineered for exterior walls, attics, exposed floors, basements, and crawl spaces where a rated R-value is required. Available from R14 through R32, fitting 2×4 through 2×8 stud cavities with higher density, better fire resistance, and added sound reduction vs. standard fiberglass batts.

Specifications

1.1 Quiet Guard ThermaBatt™ — Sizes & Coverage

Application	R Value	Width (inch)	Length (inch)	Thickness (inch)	Pcs per Bundle
wood stud	R14-16″	15.25	47	3.5	12
	R14-24″	23	47	3.5	8
	R22-16″	15.25	47	5.5	8
	R22-24″	23	47	5.5	5
	R24-16″	15	47	5.5	6
	R24-24″	22.75	47	5.5	4
	R28-16″	15.25	47	7.25	6
	R28-24″	23	47	7.25	4
	R32-16″	15.25	47	8	6
	R32-24″	23	47	8	4
steel stud	R14-16″	16.25	48	3.5	12
	R14-24″	24.25	48	3.5	8
	R22.5-16″	16.25	48	6	8
	R22.5-24″	24.25	48	6	5
	R24-16″	16.25	48	6	8
	R24-24″	24.25	48	6	5
	R32-24″	16.25	48	8	6

1.2 Quiet Guard AcousBatt™ — Sizes & Coverage

Application	Size	Width (inch)	Length (inch)	Thickness (inch)	Pcs per Bundle
wood stud	16″	15.25	47	3	12
	24″	23	47	3	8
	16″	15.25	47	6	6
	19.2″	19.2	47	3	10
	24″	23	47	6	4
steel stud	16″	16.25	48	3	12
	24″	24.25	48	3	8
	16″	16.25	48	6	6
	19.2″	19.2	48	6	5

1.3 Technical Parameters

Test Item	Unit	Test Value	Test Method
Nominal Density	lb/ft³	2.5 lb/ft³	—
Thermal Conductivity (Average Temperature 25℃)	W/m·K	0.03399–0.043	ASTM C518–13
Non-fibrous content	%	Non-Fibrous Material = 8.55%	ASTM C1335-12, Procedure B
Water vaporsorption	%	Water Vapor Sorption by Weight = 0.1% Water Vapor Sorption by Volume = 0.0%	ASTM C1104-13a, Procedure A
Max Service Temperature	℃	649	ASTM C411
Service temperature	℃	350–650	ASTM C411
Surface Burning Characteristic	Flame Spread Index	0	ASTM E84-14 (UL 723, UBC8-1, NFPA255)
Surface Burning Characteristic	Smoke Developed Index	0	ASTM E84-14 (UL 723, UBC8-1, NFPA255)
Surface Burning Characteristic	Flame Spread rating	0	CAN/ULC S102-10
Surface Burning Characteristic	Smoke Developed classification	0	CAN/ULC S102-10
Health and Safety	Resistance to Fungi	Growth rating: < Comparative Material	ASTM C1338-14
	Odor Emission	No Irritating Odor	ASTM C665
	Corrosion Resistance	No Chemical Reaction	ASTM C665

Features

Non-Inflammability — Class A1 — Melting temperature >1,000℃; Flame Spread Index 0; Smoke Developed Index 5. Does not produce toxic fumes or melt droplets in fire.
Excellent Thermal Insulation — Long and thin rock wool fiber, low slag ball content; thermal conductivity 0.034–0.043 W/(m·K) (ASTM C518).
Hydrophobicity & Moisture Resistance — Hydrophobicity rate >99%; water vapor sorption by weight only 0.1% (ASTM C1104).
Sound Absorption & Noise Reduction — Porous connected structure formed by elongated fibers delivers STC improvement up to 10 points vs. empty cavity.
Easy Construction — Easy to carry, cut, and friction-fit; high dimensional stability. No staples or adhesives required.
Weatherability — Anti-frost, freeze-thaw, UV resistant; no thermal expansion/contraction across four seasons.
Environmental Safety — pH 7–8; non-corrosive to steel and aluminum. Contains no asbestos, CFC, HFC, or other harmful substances.

Applications

Interior partition walls — bedrooms, bathrooms, home theaters, music rooms (AcousBatt 3″ or 6″)
Between-floor assemblies — STC upgrade for multi-story homes
Exterior walls — 2×4 / 2×6 new construction and retrofit (ThermaBatt R14–R24)
Attic floors & cathedral ceilings — R28 / R32 (ThermaBatt)
Exposed floors above crawl space — R22–R28 (ThermaBatt)
Basement rim joists — R14 (ThermaBatt)
Steel stud commercial walls — both series in 16″ and 24″ O.C.
